Product Overview
Manual or Auto Reset Wired Smoke Detector Relay Output
Photoelectric detector detects the smoke by a couple of infrared diodes. The principle of detecting is granule in the smoke can reflect infrared light.Infrared diodes are placed in the special chamber.
The detector works once connected to DC power directly. Operation Indicator flashing signifies detector working normally and Alarming Indicator on signifies detector alarming. Built-in a couple of output contact, contact connect/disconnect after alarm. Power-down/Auto-reset when no smoke exiting nearby. Installing with mounting base.
Shop at vedardalarm.com
INFRARED PHOTOELECTRONIC SENSOR
POWER-DOWN/AUTO RESER
INTELLIGENT LOGIC CONTROL
ALARM OUTPUT NO/NC
NETWORK OUTPUT/LED INDICATING ALARM
ANTI-LIGHT, MOTHPROOF,DUSTPROOF
STRONG ADAPTABILITY FOR CIRCUMSTANCE
SMT DESGN,HIGH STABILITY
STAIN STEELESS SHIELD,ANTI-RFI(20V/m-1GHz)
Technical Specification
Operating Voltage: DC9-35V
Standby current: 2mA(24V NO/13MA 24VNC)
Alarm current: 18mA (24Vno) 6mA(24v nc)
Alarm Indication: RED LED ON
Alarm Output: RELAY OUTPUT
CONTACT RATING ：1A @DC5V/DC48V
Sensitivity: 0.5db/m (+-0.1db/m)
Demension: 103mm*53mm
